Upgrade EDI Modules For Advanced And Environmentally Friendly Solution

Name: Upgrade EDI Modules For Advanced And Environmentally Friendly Solution
Brand: VEOLIA
Price: 1 USD

China Upgrade EDI Modules For Advanced And Environmentally Friendly Solution wholesale

Brand Name : VEOLIA

Model Number : MK-3

Certification : CE

Place of Origin : China

MOQ : 1 pc

Price : Negotiable

Supply Ability : 60000 Unit/Units per Month

Delivery Time : 5- 8 work days

Packaging Details : standard export packing

Material : Nylon or PVC

Product Dimension : 420mm x 460mm x 680mm

Lamp Base : G38

Usage : Decoration

Size : Various sizes available

Input Power : 300w constant

Gas : filled by Helium

Type : Advertising lighting balloon

Scene : Indoor or Outdoor

Remote Mode : DMX512, 2.4GHz remote controller, APP

Power : Various wattages available

Electronic Ballast : 1200w, 50-60Hz

Outside Dimension : 33x39x15cm

Shape : Round or square

Scenes : Film and television shooting lighting

Contact Now

The advantages of Electrodeionization (EDI) compared to Mixed Bed systems are numerous. EDI offers a more advanced technology, eliminating the need for regeneration chemicals or neutralization systems. This results in significantly lower operating costs and a more environmentally friendly solution. Additionally, EDI systems offer continuous and simplified operation, leading to improved process efficiency. Furthermore, with a smaller footprint and reduced building height requirement, EDI systems are easier to integrate into existing industrial facilities. Overall, EDI technology offers a cost-effective, environmentally friendly, and efficient alternative to Mixed Bed systems.

Upgrade EDI Modules For Advanced And Environmentally Friendly Solution

parameter data

Stack Name		MK-3PharmHT	MK-3MiniHT
Weight Dimensions	Shipping weight (kg)	92	52
Weight Dimensions	Dimensions (cm as width x height x depth)	30 x 61 x 54	30 x 61 x 29
Feed Water Quality Specifications	Total exchangeable anions (ppm as CaCO3)	< 25	< 25
	Conductivity (μS/cm)	< 43	< 43
	pH	4-11	4-11
	Temperature (°C)	4.4-40	4.4-40
	Hardness (ppm as CaCO3)	< 1.0	< 1.0
	Silica (ppm as SiO2)	< 1.0	< 1.0
	TOC (ppm)	< 0.5	< 0.5
	Turbidity (NTU)	< 1.0	< 1.0
	Color (APHA)	< 5	< 5
	Chlorine (ppm)	< 0.05	< 0.05
	Fe, Mn, H2S (ppm)	< 0.01	< 0.01
	Oxidant	Not detected	Not detected
	Oil and grease	Not detected	Not detected
	SDI15	< 1.0	< 1.0
Product Water Quality	Resistivity (MOhm-cm)	> 10	> 10
Product Water Quality	TOC (ppb)	< 500	< 500
Operating Parameters	Maximum water production (m3/hr)	4.5	1.5
	Minimum water production (m3/hr)	1.6	0.5
	Typical designed water production (m3/hr)	2.0-4.5	0.5-1.5
	Recovery	Up to 96%	Up to 93%
	Voltage (VDC)	0-300	0-150
	Amperage (ADC)	0-5.2	0-5.2
	Inlet pressure (bar)	Counter-current: 4.1-6.9 Co-current: 3.1-6.9	Counter-current: 4.1-6.9 Co-current: 3.1-6.9
	Dilute inlet/outlet standard pressure drop (bar)	1.4-2.8	1.4-2.8
	Minimum pressure diﬀerence between dilute outlet and concentrate inlet (bar)	0.34	0.34
	Number of 1 hour sanitization cycles	160	160
	Maximum sanitization temperature (°C)	85	85
